Vortex Mixer

The Pinnacle laboratory equipment is an exceptional solution for all your laboratory mixing needs. It offers a host of features that enhance its functionality and usability. Here are the key features presented in a reader-friendly, bullet-point format:

  • Wide Speed Range: The equipment offers an impressive speed range of 0-3000rpm, ensuring optimal mixing capabilities.

  • Fast Mixing: It can thoroughly mix full 50ml containers in just 3 seconds, enhancing efficiency.

  • Multiple Modes: It features touch mode, timer mode, and continuous mode, providing varied operational options.

  • Brushless DC Motor: The equipment is equipped with a brushless DC motor, which ensures durability and long-term use.

  • Sturdy Base: The base is made of robust iron/aluminum casting, providing stability during operation.

  • Compact Design: The compact design makes it easy to use and store, making it a perfect fit for any laboratory.

  • Low Operation Voltage: The equipment operates at a low voltage of 12V, ensuring safety and energy efficiency.

  • Dynamic Balance Design: The perfect dynamic balance design eliminates any movement in mixing, ensuring precision in results.

  • Compatibility: It is compatible with multiple voltage options and various interchangeable attachments, making it versatile and adaptable to different laboratory needs.

The Pinnacle laboratory equipment is a must-have for any laboratory looking to improve efficiency and precision in mixing processes. Its robust features and exceptional performance make it a standout choice in the market.

NOTE: Institutional & Contract Discounts Available - Enquire For Pricing

Description

The Pinnacle laboratory equipment, the perfect solution for your mixing needs. With a wide speed range of 0-3000rpm and an orbital diameter of 6mm, this equipment offers excellent mixing capability, making full 50ml containers mix within 3 seconds. It features touch mode, timer mode and continuous mode, with a brushless DC motor and sturdy iron/aluminum casting base for durability. The compact design and low operation voltage(12V) make it easy to use and store, while the perfect dynamic balance design eliminates any movement in mixing. Compatible with multiple voltage options and various interchangeable attachments, this equipment is a must-have for any laboratory.

Additional information

Operation Mode

Continuous / touch operation

Type of Movement

Orbital

Orbital Diameter

6mm

Speed Range

0-3000rpm

Speed Display

Scale

Permissible Ambient Temperature

5-40°C

Permissible Relative Humidity

80%

Protection class accordin to DIN EN 60529

IP21

Voltage [VAC]

200-240 / 115 /100V compatible

Power [W]

36

Frequency [Hz]

50/60

Motor Rating Input [W]

30

Motor rating output [W]

15

Dimensions (W x H x D)

107x146x166mm

Weight [kg]:

3
