10 Position Magnetic Hotplate Stirrer
The Pinnacle Laboratory Magnetic Stirrer is a versatile tool that offers precision control and consistent stirring. It is compact, lightweight, and suitable for either continuous or timed operation. Here are some of its key features:
- 10 Stirring Positions: This stirrer comes with ten stirring positions, allowing for maximum flexibility and precision in your laboratory work.
- Electromagnetic Drive: The electromagnetic drive ensures consistent stirring across all positions.
- Large Work Plate: The stainless steel work plate measures 470x205mm and is coated with a silicone surface for easy cleaning and durability.
- High Stirring Capacity: It can handle a maximum stirring quantity of 0.4 x 10L, making it suitable for large-scale experiments.
- Adjustable Heating Temperature: The stirrer features a heating temperature range from room temperature up to 120℃.
- Reverse Rotation: This feature allows for adjustable reverse rotation, enhancing the stirrer’s versatility.
- LED Displays: The stirrer comes with LED displays for speed and time, enabling easy monitoring of your experiments.
- Energy Saving: The economic mode helps to save energy, making this stirrer an eco-friendly choice for your laboratory.
- Safety Features: With its IP30 protection class, the stirrer ensures safety during operation.
Invest in the Pinnacle Laboratory Magnetic Stirrer for precision, control, and safety in your laboratory work.
NOTE: Institutional & Contract Discounts Available - Enquire For Pricing
Description
The Pinnacle laboratory magnetic stirrer, a compact and lightweight tool that is perfect for continuous or timed operation. With 10 stirring positions and an electromagnetic drive, this stirrer offers precision control and consistent stirring on all positions. The stainless steel work plate with silicone surface measures 470x205mm and can handle a max stirring quantity of 0.4 x 10L. It features a heating temperature range of room temp. to 120℃, adjustable reverse rotation, and LED displays for speed and time. The economic mode saves energy, while the IP30 protection class ensures safety.
Additional information
| Stirring Position | 10 |
|---|---|
| Work Plate Material | Stainless steel with silicone |
| Work Plate Dimension [L x W, mm] | 470×205 |
| Driving Mode | Electromagnetic drive |
| Max. Stirring Quantity [L] | 0.4 x 10 |
| Heating Temperature [] | Room temp. – 120 |
| Safety Temperature [] | 150 |
| Speed Range [rpm] | 0-1200 |
| Speed Increment [rpm] | 10 |
| Stirring Position Distance [mm] | 93 |
| Max. Magnetic Bar [L, mm] | 30 |
| Speed Display | LED |
| Time Display | LED |
| Economic Mode | Yes |
| Adjustable Reverse Rotation | Yes |
| Operation Type | Continuous / Timing Operation |
| Time Range | 0-99h59min |
| Voltage [VAC] | 100-120/200-240 |
| Frequency [Hz] | 50/60 |
| Heating Power [W] | 500 |
| Power [W] | 580 |
| Permissible Ambient Temperature [] | 5-40 |
| Permissible Relative Humidity | 80% |
| Protection Class | IP30 |
| Dimension [L x W x H, mm] | 630x210x70 |
| Weight [kg] | 10 |
